Mezzanine Cards
Wideband RF transmit or receive mezzanines with integrated digital tuning and control.
Complete RF front-end in a 130 by 20 mm mezzanine (stick) with full signal isolation, customizable for your mission application.
Miniaturized, intelligent and customizable
Highly integrated wideband RF Tx and Rx mezzanines digitally enabled, and customizable for your application requirements.
Standard configurations are single- and dual-channel packages. Other configurations and packages are available. Contact sales@spectrumcontrol.com for more information.
Unmatched RF Density. We achieved breakthrough miniaturization using a novel model-based design and state-of-the-art SMT packaging allowing us to reduce the size of a complete wideband RF front-end into a 130 by 20 mm mezzanine (stick) with full signal isolation.
Digital Interface. Built into each mezzanine is a digital interface for system tuning, channel control and health & configuration. Each mezzanine contains its own factory-set frequency and temperature calibration data minimizing the need for additional system calibration. This integral digital capability, with a simple 4-wire interface, also dramatically simplifies system integration.
Customization. Standard form factors include single- and dual-channel configurations in metal enclosures with coaxial connections. Customizations include mounting, connectors (RF, control, power). Additional special functionality for multiple mezzanines is available (example: coherent LOs).
Technical Overview
- Wideband signal fidelity: monitoring of 0.02-18 GHz with 2 GHz IBW
- Integrated digital gateway for command/control with health/temperature monitoring
- Designed for high volume production and optimized to minimize supply chain risk
- IF calibration for optimum spectral performance
- Integrated LO generation for independent tuning capability
- Can be tuned coherently for direction finding (DF) applications
- Continuous health monitoring
- 12/28 VDC power input
- US-manufactured and sourced
Want to learn more?
Due to the nature of this technology, we are limiting the release of specifics at this time. If you’d like more information about product availability and customization needs, please contract the Spectrum Control team directly or use this secure form to be introduced to the team.
